S-Record Format
Creating S-records
NOTE
The Freescale ICE Base (FSICEBASE) supports only the S0, S1, and S9 record
types. All data before the first S1 record is ignored. Thereafter, all records must
be S1 type until the S9 record, which terminates data transfer.
Table A.2 S-Record Types
Type
S0
S1
S2-S8
S-9
Description
Header record for each block of S-records. The code/data field may contain any
descriptive information identifying the following block of S-records. The address
field is normally zeros.
Code/data record and the two-byte address at which the code/data is to reside.
Not supported by the FSICEBASE.
Termination record for a block of S1 records. Address field may optionally contain
the two-byte address of the instruction to which control is to be passed. If not
specified, the first interplant specification encountered in the input will be used.
There is no code/data field.
Only one termination record is used for each block of s-records. Normally, only one
header record is used, although it is possible for multiple header records to occur.
Creating S-records
S-record format programs may be produced by dump utilities, debuggers, cross
assemblers, or cross linkers. Several programs are available for downloading a file in S-
record format from a host system to an 8-bit or 16-bit microprocessor-based system.
Example
A typical S-record format looks like this when printed or displayed:
S00600004844521B
S1130000285F245F2212226A000424290008237C2A
S11300100002000800082529001853812341001813
S113002041E900084E42234300182342000824A952
S107003000144ED492
S9030000FC
Freescale In-Circuit Emulator Base User Manual, Rev. 1.1
Freescale Semiconductor
77
